S66286

Product:S66286 is A Fe - ni - cr 15 25 based high temperature alloy, molybdenum, titanium, aluminum, vanadium and trace boron composite reinforcement. Under 650 degree has high yield strength and lasting and creep strength, and has good processing plastic and satisfactory welding performance. Suitable for manufacturing in the long-term work of aircraft engine under 650 degree high temperature bearing parts, such as turbine disc, press plate, the rotor blades and fasteners, etc. Can produce all kinds of deformation in the shape of the alloy products, such as plate, forgings, plate, bar, wire and circular pieces, etc.

S66286 steel equal material : Incoloy A - 286,ZbNCT25

2. S66286 alloy chemical composition %

≤0.08

13.5-

16.0

24.0-

27.0

1.00-

1.50

1.75-

2.30

0.10-

0.50

0.001-0.010

1.00-

2.00

≤0.04

≤1.00

≤0.030

≤0.020

remaining

Note: S66286 Cold drawing steel rods, S66286 steel disc and S66286 steel ring standard rules (Ti)1.80%-2.35%。
S66286 Hot rolled steel sheet and S66286 cold rolled steel sheet standard requirements (B)0.003%-0.010%, (Mn)≤2.00%, (P)≤0.020%, (S)≤0.015%。
S66286 Cold drawn wire standard request (Al)≤0.35%, (Ti)1.75%-2.35%, (Si)0.40%-1.00%, (P)≤0.020%, (S)≤0.015%。
S66286 Cold heading with silk material standards request: (Ti)1.75%-2.35%, (Si)0.40%-1.00%, (P)≤0.025%, (S)≤0.020%。
S66286 Hot rolled and forged bar standard request (Cu)≤0.25%。

High-quality S66286 alloy chemical composition %

C	Cr		Ni		Mo		Ti	Fe		V		B		Mn		Al	Si		P		S
														≤
≤0.08	13.50-16.00		24.00-27.00		1.00- 1.50		1.90- 2.35	remaining		0.10-0.50		0.003-0.010		0.35		0.35	0.35		0.015		0.002
Ca		Mg		Cu			Sn	Pb	Se		Ag		Te		Tl	Bi		N		O
≤
0.005		0.005		0.30		0.0050		0.0005	0.0003		0.0005		0.00005		0.0001	0.00003		0.0100		0.0050

3. S66286 Heat treatment system are shown in the following table.

Quality S66286 heat treatment is at 900 degree plus or minus 10 degree, 1 ~ 2 h, oil cooled to + 750 degree + 10 degree, 16 h, air cooling.

Product	Heat treatment system
S66286 Rod bar, disc	980-1000 degree,1-2h, Oil cooling＋700-720 degree, 12-16h, Air cooling
S66286 Hot rolled / cold rolled plates	980-1000 degree, Air cooling＋700-720degree, 12-16h, Air cooling
S66286 Cold drawn rod	980-1000 degree,1-2h,Oil cooling＋700-720℃,16h, Air cooling
S66286 Ring	980-990 degree 1-2h, Oil cooling＋700-720degree, 16h, Air cooling
S66286 cold drawing wire	980-1000degree, Water cooling or Oil cooling＋700-720 degree,16h, Air cooling

Product

About Us

Manufacture

Name：
Email：
Tel：
Message：
