N06617 corrosion-resisting nickel-base alloy is a kind of nickel-chromium-cobalt- molybdenum alloy which has the excellent mechanical property at high temperature;the alloy has high temperature corrosion resistance, such as the oxidation and carbonization.
N06617 equal material :W.Nr.2.4663 , NiCr23Co12Mo, Inconel 617, NiCr22Co12Mo9
2. N06617 corrosion-resisting nickel-base alloy Chemical composition
|
Nickel |
Cr |
Fe |
C |
Mn |
Si |
Mo |
Co |
Al |
Ti |
P |
S |
min |
balance |
20 |
|
0.05 |
|
|
8.0 |
10.0 |
0.6 |
0.2 |
|
|
max |
23 |
2.0 |
0.1 |
0.7 |
0.7 |
10.0 |
13.0 |
1.5 |
0.6 |
0.012 |
0.008 |
N06617 alloy steel properties:
N06617 corrosion-resisting nickel-base alloy density:8.4g/cm3
N06617 alloy steel melting temperature range:1330-1380 degree
N06617 mechanical properties minimum value at room temperature :
Product |
Thickness /OD mm |
Test direction |
Tensile strength MPa |
Yield strength MPa |
Yield strength MPa |
Elongation A5% |
sheet, strip |
Cold rolled≤6 |
Transverse |
750 |
350 |
390 |
35 |
plate |
Hot-rolled<80 |
Transverse |
700 |
300 |
330 |
35 |
Bar |
≤300 |
Transverse |
680 |
300 |
330 |
30 |
≤300 |
Radial |
680 |
300 |
330 |
35 |
|
Pipe/tube |
≤150 |
Radial |
700 |
300 |
330 |
35 |
N06617 alloy steel application:
N06617 is Suitable for high temperature and high mechanical stress. Recommended temperature does not exceed 1000 degree. At the same time, N06617 is suitable for the occasion where the weight should be reduced, like thin wall parts processing, and so on. Specially in Industrial and aviation turbine components, air heater, muffle and radiation Museum, the high temperature heat exchanger, valve and spring, the high temperature gas cooled nuclear reactors(such as high temperature components - nuclear reactor helium and helium heat exchanger), chemical equipment, the petrochemical industry of spiral tube and pipe.
