N10276 material is a kind of Ni-Cr-Mo alloy containing tungsten with very low content of the silicon and carbon.N10276 Characteristic: in oxidizing and reducing conditions, N10276 has excellent corrosion resistance to most corrosive medium. the excellent Corrosion resistance, crevice corrosion and stress corrosion cracking performance.
1.N10276 equal material: W.Nr.2.4610,NiMo16Cr16Ti, UNS N06455,Hastelloy C-276
2. N10276 corrosion-resisting alloy steel chemical composition:
|
Ni |
Cr |
Fe |
C |
Mn |
Si |
Mo |
W |
Co |
V |
P |
S |
minimum |
balance |
15.0 |
4.0 |
|
|
|
15.0 |
3.0 |
|
0.1 |
|
|
maximum |
16.5 |
7.0 |
0.01 |
1.0 |
0.08 |
17.0 |
4.5 |
2.5 |
0.3 |
0.015 |
0.01 |
N10276 alloy steel density:8.9g/cm3
N10276 alloy steel Melting temperature range: 1325-1370 degree
4.N10276 corrosion-resisting alloy steel application:
N10276 has been widely used in chemical and petrochemical, such as element application chloride containing organic compounds in contact and catalytic system. This material is particularly suitable for high temperature, mixed with inorganic acid and organic acid impurities (such as formic acid and acetic acid), the use of seawater corrosion environment.
Other special applications:
The pulp and paper industry, such as cooking and bleaching solution container
The FGD system in the washing tower, heater, fan, wet steam
Equipment and components, work in the acidic gases in the environment
Reactor, acetic acid and acidic products
sulfuric acid condenser
methylene two phenyl isocyanate (MDI)
impure phosphoric acid production and processing
5.N10276 Processing and heat treatment:
N10276 solid solution treatment temperature is in the range of 1100 - 1160 degree .
The method of cooling water quenching, thickness of less than 1.5mm material also can use rapid cooling. If the air cooling, it should be from 1000 degree to 600 degree cooling in 2 minutes.
In the process of heat treatment, must keep the workpiece cleaning.
Related Link:Hastelloy C-22,Hastelloy C-276,Hastelloy C,Hastelloy X,Nickel alloys and super alloys
