NiCu30Fe
NiCu30Fe

Equal material : B127, ASME SB-127, AMS 4554, JIS NW4400 , Monel 400, NiCu30FeW-Nr: 2.4360, MCu-28-1.5-1.8 , BS NA 12

NiCu30Fe alloy is a kind of corrosion resistance of nickel copper alloy, its organization into a single phase high strength of solid solution. Having excellent corrosion resistance in hydrofluoric acid and fluorine gas medium; also have excellent corrosion resistance to hot concentrated alkaline solution; at the same time also resistant to neutral solution, halogen, high temperature, water, sea water, all kinds of food, a variety of organic compounds in atmospheric corrosion. Generally no stress corrosion crack, good cutting performance.

NiCu30Fe alloy chemical composition



Ni

Fe

C

Mn

Si

Al

Cu

S

minimum

63.0







28



maximum



2.5

0.3

2.00

0.50

0.50

34

0.024

NiCu30Fe alloy mechanical property

Alloy and state

Strength of extension
Rm N/mm2

Yield strength
RP0.2N/mm2

ductility
A5 %

NiCu30Fe

480

170

35

NiCu30Fe physical properties
NiCu30Fe density : 8.83 g/cm3

NiCu30Fe alloy Common product forms and specifications:
NiCu30Fe alloy bar diameter 11-300mm Rolled or forged
NiCu30Fe alloy Disc Rolled or forged diameter 100-2000mm
NiCu30Fe alloy cold draw diameter 6-75mm Cold drawn
Ring diameter 1000mm Conventional products, large-scale.
Strip 0.15-22 mm thickness cold rolled or hot rolled
NiCu30Fe alloy wire diameter 0.1--9 mm
NiCu30Fe alloy pipe meter OD 6-219mm *0.1-40 mm a variety of cold-rolled, cold drawn pipe

NiCu30Fe executive standard
tube stock: ASME SB163/ B165
Bar: ASME SB164
Board: ASME SB127

NiCu30Fe alloy material chief application
NiCu30Fe alloy products mainly used in marine heat exchangers, seawater desalination equipment, production equipment, the sea salt and chemical processing equipment, the propeller shaft and water pump, gasoline and water tank, chemical, petrochemical, oil, nuclear industry, salt chemical industry, electronic industry and other fields.

Related Link:Monel 400,Monel K-500,Monel 405,Nickel alloys and super alloys
