Equal material : B127, ASME SB-127, AMS 4554, JIS NW4400 , Monel 400, NiCu30FeW-Nr: 2.4360, MCu-28-1.5-1.8 , BS NA 12
N04400 alloy is a kind of corrosion resistance of nickel copper alloy, its organization into a single phase high strength of solid solution. Having excellent corrosion resistance in hydrofluoric acid and fluorine gas medium; also have excellent corrosion resistance to hot concentrated alkaline solution; at the same time also resistant to neutral solution, halogen, high temperature, water, sea water, all kinds of food, a variety of organic compounds in atmospheric corrosion. Generally no stress corrosion crack, good cutting performance.
N04400 alloy chemical composition
|
Ni |
Fe |
C |
Mn |
Si |
Al |
Cu |
S |
minimum |
63.0 |
|
|
|
|
|
28 |
|
maximum |
|
2.5 |
0.3 |
2.00 |
0.50 |
0.50 |
34 |
0.024 |
N04400 alloy mechanical property
Alloy and state |
Strength of extension |
Yield strength |
ductility |
N04400 |
480 |
170 |
35 |
N04400 physical properties
N04400 density : 8.83 g/cm3
N04400 alloy Common product forms and specifications:
N04400 alloy bar diameter 11-300mm Rolled or forged
N04400 alloy Disc Rolled or forged diameter 100-2000mm
N04400 alloy cold draw diameter 6-75mm Cold drawn
Ring diameter 1000mm Conventional products, large-scale.
Strip 0.15-22 mm thickness cold rolled or hot rolled
N04400 alloy wire diameter 0.1--9 mm
N04400 alloy pipe meter OD 6-219mm *0.1-40 mm a variety of cold-rolled, cold drawn pipe
N04400 executive standard
tube stock: ASME SB163/ B165
Bar: ASME SB164
Board: ASME SB127
N04400 alloy material chief application
N04400 alloy products mainly used in marine heat exchangers, seawater desalination equipment, production equipment, the sea salt and chemical processing equipment, the propeller shaft and water pump, gasoline and water tank, chemical, petrochemical, oil, nuclear industry, salt chemical industry, electronic industry and other fields.
