Equal material :B127, ASME SB-127, AMS 4554, JIS NW4400 , Monel 400,UNS N04400,MCu-28-1.5-1.8 , BS NA 12
W.Nr.2.4360 alloy is a kind of corrosion resistance of nickel copper alloy, its organization into a single phase high strength of solid solution. Having excellent corrosion resistance in hydrofluoric acid and fluorine gas medium; also have excellent corrosion resistance to hot concentrated alkaline solution; at the same time also resistant to neutral solution, halogen, high temperature, water, sea water, all kinds of food, a variety of organic compounds in atmospheric corrosion. Generally no stress corrosion crack, good cutting performance.
W.Nr.2.4360 alloy chemical composition
|
Ni |
Fe |
C |
Mn |
Si |
Al |
Cu |
S |
minimum |
63.0 |
|
|
|
|
|
28 |
|
maximum |
|
2.5 |
0.3 |
2.00 |
0.50 |
0.50 |
34 |
0.024 |
W.Nr.2.4360 alloy mechanical property
Alloy and state |
Strength of extension |
Yield strength |
ductility |
W.Nr.2.4360 |
480 |
170 |
35 |
W.Nr.2.4360 physical properties
W.Nr.2.4360 density : 8.83 g/cm3
W.Nr.2.4360 alloy Common product forms and specifications:
W.Nr.2.4360 alloy bar diameter 11-300mm Rolled or forged
W.Nr.2.4360 alloy Disc Rolled or forged diameter 100-2000mm
W.Nr.2.4360 alloy cold draw diameter 6-75mm Cold drawn
Ring diameter 1000mm Conventional products, large-scale.
Strip 0.15-22 mm thickness cold rolled or hot rolled
W.Nr.2.4360 alloy wire diameter 0.1--9 mm
W.Nr.2.4360 alloy pipe meter OD 6-219mm *0.1-40 mm a variety of cold-rolled, cold drawn pipe
W.Nr.2.4360 executive standard
tube stock: ASME SB163/ B165
Bar: ASME SB164
Board: ASME SB127
W.Nr.2.4360 alloy material chief application
W.Nr.2.4360 alloy products mainly used in marine heat exchangers, seawater desalination equipment, production equipment, the sea salt and chemical processing equipment, the propeller shaft and water pump, gasoline and water tank, chemical, petrochemical, oil, nuclear industry, salt chemical industry, electronic industry and other fields.
